CviJI, (CviJI)

Marka:EURx

Ürün Ölçü Fiyat TL Miktar
CviJI, (CviJI)
E2125-01
100 u 180,8 EUR
+%20 KDV
8.895,36 TL
CviJI, (CviJI)
E2125-02
400 u 576 EUR
+%20 KDV
28.339,20 TL

CviJI

(Chlorella virus IL-3A)

5’-Pu G C Py-3’
3’-Py C G Pu-5’

Note 1: Purified from E.coli strain that carries the cloned cvijRI gene from Chlorella virus IL-3A (Patent No. US005472872A)

Reaction Temperature: 37°C

Prototype: CviJI

Inactivation Temperature (20 min): 50°C

Reaction Buffer:

1x CviJI Buffer: 20 mM glycylglycine-KOH (pH 8.5), 10 mM magnesium acetate, 50 mM potassium acetate, 0.1 mM dithiothreitol, 10% DMSO

Note 2: reaction buffer is provided as 5x concentrated stock.

Unit Definition: One unit is the amount of enzyme required to completely digest 1 µg of pBR322 DNA in 1 hour in a total reaction volume of 25 µl.

Description:

CviJI is the only available restriction endonuclease recognizing two-three base pair sequence (1,2,3), thus allowing for new research applications (4). This recombinant version of CviJI cleaves only PuGCPy sites (4). It does not exhibit star activity (CviJI*) (1,2), thus it is better suited for high resolution mapping of short DNA's like amplified products or small plasmids. Other CviJI applications, like shotgun cloning, thermal cycle labeling (5) or epitope mapping can be performed either with this version or with CviJI*.

Assay Conditions: 20 mM glycylglycine-KOH (pH 8.5), 0.1 mM dithiothreitol, 50 mM potassium acetate, 10% DMSO, 10 mM magnesium acetate, 1 µg of pBR322. Incubation is at 37°C for 1 hr in a reaction volume of 25 µl.

Storage Buffer: 20 mM Tris-acetate (pH 8.0 at 22°C), 50 mM potassium acetate, 0.5 mM EDTA, 3 mM dithiothreitol, 5 mM magnesium acetate and 50% (v/v) glycerol.

Storage Conditions: Store at –20°C.

Quality Control:

Non-specific Endonuclease: Incubation of 10 units of CviJI with 1 µg of pUC19 plasmid DNA at 37°C for 16 hrs (a 160-fold over-digestion) resulted in the same sharp characteristic banding pattern as the standard assay reaction, as determined by agarose gel electrophoresis.

3'-Exonuclease: 5, 10 and 20 units of CviJI and 0.13 µg (0.65 pmol of 3'-ends) of lambda/TaqI fragments (3'-labeled with T4 DNA Polymerase and [³H]dGTP and [³H]dCTP), incubated for 1 hr at 37°C resulted in 0.03 slope of %-end label released per unit of enzyme. Reaction volume 10 µl.

5'-Exonuclease/5'-Phosphatase: Incubation of 5, 10 and 20 units of CviJI with 0.05 µg (0.30 pmol of 5'-ends) of [5'-³³P]lambda/HaeIII fragments for 1 hr at 37°C resulted in 0.024 slope of %-end label released per unit of enzyme. Reaction volume 10 µl.

References:

  1. Xia,Y., Burbank, D., Uher, L., Rabussay, D. and Van Etten, J. Nucleic Acids Res.15, 6075-6090.

  2. Fitzgerald,M.C., Skowron, P., Van Etten, J.L., Smith, L.M. and Mead, D.A. (1992) Nucleic Acids Res. 20, 3753-3762.

  3. Mead, D., Swaminathan, N., Van Etten J. and Skowron, P.M.: Recombinant CviJI restriction endonuclease. (1995) Unites States Patent no US005472872A.

  4. Skowron, P.M, Swaminathan, N., McMaster, K., George, D., Van Etten, J. and Mead, D. Gene 157 (1995) 37-41.

  5. Swaminathan, N., McMaster, K., Skowron, P. and Mead, D.A. Analytical Biochemistry 255 (1998) 133-141.
